NM-II PLUS Series
- Category：Off Grid Solar Invetert
- Clicknum：次
- Intro：
● Pure sine wave solar inverter
● Output power factor 1.0
● Wifi&GPRS available for IOS and android
● Inverter can run without battery
● Built-in 100A MPPT solar charger
- Detail
Features
● Pure sine wave solar inverter
● Output power factor 1.0
● Wifi&GPRS available for IOS and android
● Inverter can run without battery
● Built-in 100A MPPT solar charger
● High PV input voltage range(120~450VDC)
● Built-in anti-dust kit for harsh environment
● Smart battery charge design to optimize battery life
Product Data Sheet
| MODEL | VICTOR NM-II-3500W-PLUS | VICTOR NM-II-5500W-PLUS |
| Rated Power | 3500VA/3500W | 5500VA/5500W |
| AC INPUT | ||
| Voltage | 230VAC | |
| Selectable Voltage Range | 170~280VAC(For Personal Computers) 90~280VAC(For Home Appliances) | |
| Frequency Range | 50 Hz/60Hz(Auto sensing) | |
| AC OUTPUT | ||
| AC Voltage Regulation(Batt.Mode) | 230VAC±5% | |
| Surge Power | 7000VA | 11000VA |
| Efficiency(Peak)PV to INV | 97% | |
| Efficiency(Peak)Battery to INV | 94% | |
| Transfer Time | 10 ms (For Personal Computers)20 ms (For Home Appliances) | |
| BATTERY & AC CHARGER | ||
| Battery Voltage | 24VDC | 48VDC |
| Floating Charge Voltage | 27VDC | 54VDC |
| Overcharge Protection | 33VDC | 63VDC |
| Maximum Charge Current | 80A | |
| SOLAR CHARGER | ||
| Maximum PV Array Power | 5000W | 6000W |
| MPPT Range @ Operating Voltage | 120~450VDC | |
| Maximum PV Array Open Circuit Voltage | 500VDC | |
| Maximum Charging Current | 100A | |
| Maximum Efficiency | 98% | |
| PHYSICAL | ||
| Dimension ,H*W*D(mm) | 440*310*110 | |
| Cartoon Dimension ,H*W*D(mm) | 590*390*208 | |
| Net Weight(kgs) | 8.5 | 9.5 |
| Gross Weight(kgs) | 9.5 | 10.5 |
| Communication interface | RS232/GPRS/WIFI | |
| ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Operating Temperature | -10°C~50°C | |
| STANDARD | ||
| Compliance Safety | CE | |
