NM-ESSM Series
- Category：Energy Storage System
- Clicknum：次
- Intro：
● Pure sine wave solar inverter(on/off Grid)
● Output power factor 1.0
● WIFI&GPRS available for IOs and Android
● One-key restoration to factory Settings
● Built-in Lithium battery automatic activation
- Detail
Features
● Pure sine wave solar inverter(on/off Grid)
● Output power factor 1.0
● WIFI&GPRS available for IOs and Android
● One-key restoration to factory Settings
● Built-in Lithium battery automatic activation
● Integrated design
● Built-in 120A MPPT Solar charge: max 6200W(for 4. 2KW); max 6500W(for 6.2KW)
● High PV input voltage range(60~ 500VDC)
● Built-in anti-dust kit for harsh environment
● Smart battery charge design to optimize battery life
● Dual output
Product Data Sheet
| MODEL | VICTOR NM-ESSM-4.2KW PLUS-100AH/200AH | VICTOR NM-ESSM-6.2KW PLUS-100AH |
| Phase | ||
| Maximum PV Input Power | 6200W | 6500W |
| Rated Output Power | 4200W/4200VA | 6200W/6200VA |
| Maximum Solar Charging Current | 120A | |
| GRID-TIE OPERATION | ||
| PV INPUT (DC) | ||
| Nominal DC Voltage/Maximum DC Voltage | 360/500VDC | |
| Start-up Voltage / Initial Feeding Voltage | 60VDC/90VDC | |
| MPPT Voltage Range | 60~450VDC | |
| Maximum Input Current | 1/18A | 1/22A |
| GRID OUTPUT (AC) | ||
| Nominal Output Voltage | 220/230/240VAC | |
| Output Voltage Range | 195.5~253VAC | |
| Nominal Output Current | 18.2A | 27.0A |
| Power Factor | >0.99 | |
| EFFICIENCY | ||
| Maximum Conversion Efficiency (DC/AC) | 98% | |
| TWO LOAD OUTPUT POWER | ||
| Full Load | 4200W | 6200W |
| Maxium Main Load | 4200W | 6200W |
| Second Load Range | 840W~2940W | 1240W~4340W |
| Maxium Load Cut Off Voltage | 26VDC | 52VDC |
| Maxium Load Return Voltage | 27VDC | 54VDC |
| OFF-GRID OPERATION | ||
| AC INPUT | ||
| AC Start-up Voltage / Auto Restart Voltage | 120-140VAC/180VAC | |
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC | |
| Frequency Range | 50±1Hz/60±1Hz | |
| Maximum AC Input Current | 24.7A | 36.4A |
| PV INPUT (DC) | ||
| Nominal DC Voltage/Maximum DC Voltage | 360/500VDC | |
| MPPT Voltage Range | 60~450VDC | |
| Maximum Input Current | 1/18A | 1/22A |
| BATTERY MODE OUTPUT (AC) | ||
| Nominal Output Voltage | 220/230/240VAC | |
| Output Waveform | Pure sine wave | |
| Efficiency (DC to AC) | 94% | |
| BATTERY & CHARGER | ||
| Nominal DC Voltage | 24VDC | 48VDC |
| Maximum Solar Charging Current | 120A | 120A |
| Maximum AC Charging Current | 100A | 100A |
| Maximum Solar+AC Charging Current | 120A | 120A |
| HYBRID OPERATION | ||
| PV INPUT (DC) | ||
| Nominal DC Voltage/Maximum DC Voltage | 360/500VDC | |
| Start-up Voltage / Initial Feeding Voltage | 90VDC/120VDC | |
| MPPT Voltage Range | 60~450VDC | |
| Maximum Input Current | 1/18A | 1/22A |
| GRID OUTPUT (AC) | ||
| Nominal Output Voltage | 220/230/240VAC | |
| Output Voltage Range | 195.5~253VAC | |
| Nominal Output Current | 18.2A | 27.0A |
| AC INPUT | ||
| AC Start-up Voltage / Auto Restart Voltage | 120-140VAC/180VAC | |
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC | |
| Maximum AC Input Current | 24.7A | 36.4A |
| Maximum AC Charging Current | 100A | |
| MODEL | VICTOR NM-ESSM-4.2KW PLUS-100AH/200AH | VICTOR NM-ESSM-6.2KW PLUS-100AH | |
| BATTERY | |||
| MODEL | 25.6V100AH | 25.6V200AH | 48V100AH |
| Normal charging voltage | 29.2V | 29.2V | 54.75V |
| Maximum charging current | 100A(Recommended) | 100A/200A (Recommended100A) | 100A(Recommended) |
| Discharge termination voltage | 20V | 20V | 37.5V |
| Recommended discharge termination voltage | 22.4V | 22.4V | 42V |
| Maximum discharge current | 100A | 100A/200A | 100A |
| Single cell charging overvoltage protection | 3.65V | 3.65V | 3.65V |
| Overvoltage protection for the whole battery | 29.2V | 29.2V | 54.75V |
| Low voltage protection for single cell discharge | 2.5V | 2.5V | 2.5V |
| Low voltage protection for whole group discharge | 20V | 20V | 37.5V |
| Charge overcurrent protection | 110A | 110A/220A | 110A |
| Discharge overcurrent protection | 110A | 110A/220A | 110A |
| BMS Features | • High accuracy cell level voltage, current measuring • Over-charge, over-discharge protection • Short-circuit protection • Self-learning intelligent SOC calculation • Cell level active equalization • Multiple communication type • Parallel connect function | ||
| Working temperature | -20℃~+65℃ | ||
| Storage temperature | 0℃~+65℃ | ||
| GENERAL | |||
| PHYSICAL | |||
| Dimension ,H*W*D(mm) | 701*441*231 | ||
| Cartoon Dimension ,H*W*D(mm) | 800*530*340 | ||
| Net Weight (kgs) | 42KG | 59KG | 58KG |
| Gross Weight(kgs) | 44.7KG | 61.7KG | 60KG |
| INTERACE | |||
| Communication Port | RS232/RS485/WIFI/GPRS | ||
| ENVIRONMENT | |||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | ||
| STANDARD | |||
| Compliance Safety | CE UN38.3;MSDS | ||
