Easy access
Accessible through a LCD touch screen and through the web
BMS
More available battery energywith pack optimization Batteries flexible expansion in stages
EASY INSTALL ATION
Small, compact and lightweight for easy installation.
REMOTE MONITORING
Monitor your system remotely via smartphone or web portal.
Safe
Sleep-class silence Long battery life
Technical parameters of the battery system | ||
project name | essential parameter | remarks |
product model | 51.2V 300Ah | |
rated voltage | 51.2V | |
rated capacity | 300Ah | |
rated energy | 15360Wh | |
cooling-down method | natural cooling | |
compound mode | 16 String 1 and | |
Charge and discharge ports (common or split) | A total of | |
The communication port is RS232 / RS485 / CAN | RS485/CAN | |
display screen | With a display | |
Heating function | Default no | Can be matched first |
Battery pack charging cutoff voltage | 57.6V | Charging protection voltage |
Battery pack discharge cut-off voltage | 43.2V | Discharge to protect voltage |
Single-unit charging cut-off voltage | 3.65 | |
The monomer discharge cut-off voltage | 2.7 | |
Charging operating temperature range | -0 ~ 55°C | |
Discharge operating temperature range | -20 ~ 60°C | |
Standard charging | 0.2C current continuously charging to 57.6V cut-off | |
Standard discharge | 0.5C current continuously continuously to 43.2V cutoff | |
Maximum allowable continuous charge current | 200A | |
Maximum allowable continuous discharge current | 200A | |
Discharge protects current | 210A | |
Battery box size (length * width * height mm) | 850*525*255mm | Dimension tolerance of ± 1.5mm |
Battery Case Weight Tolerance (KG) | 125 | Weight tolerance of ± 3 KG |
