Easy access
Accessible through a LCD touch screen and through the web
BMS
More available battery energywith pack optimization Batteries flexible expansion in stages
Expansion
suport for expanding capacity and support greater output power at the same time
REMOTE MONITORING
Monitor your system remotely via smartphone or web portal
Safe
Sleep-class silence Long battery life
Technical parameters of the battery system | ||
project name | essential parameter | remarks |
product model | 51.2 V230 Ah | |
rated voltage | 51.2V | |
rated capacity | 230Ah | |
rated energy | 11776Wh | |
cooling-down method | natural cooling | |
compound mode | 16 String 1 and | |
Charge and discharge ports (common or split) | A total of | |
The communication port is RS232 / RS485 / CAN | RS485/CAN | |
display screen | With a display | |
Heating function | Default no | Can be matched first |
Battery pack charging cutoff voltage | 57.6V | Charging protection voltage |
Battery pack discharge cut-off voltage | 43.2V | Discharge to protect voltage |
Single-unit charging cut-off voltage | 3.65 | |
The monomer discharge cut-off voltage | 2.7 | |
Charging operating temperature range | -0 ~ 55°C | |
Discharge operating temperature range | -20 ~ 60°C | |
Standard charging | 0.2C current continuously charging to 57.6V cut-off | |
Standard discharge | 0.5C current continuously continuously to 43.2V cutoff | |
Maximum allowable continuous charge current | 200A | |
Maximum allowable continuous discharge current | 200A | |
Discharge protects current | 210A | |
Battery box size (length * width * height mm) | 720*525*255 mm | Dimension tolerance is ± 1.5mm |
Battery Case Weight Tolerance (KG) | 98 | Weight tolerance of ± 3 KG |
