5kWh LiFePL Battery

Easy access

Accessible through a LCD touch screen and through the web

BMS

More available battery energywith pack optimization Batteries flexible expansion in stages

EASY INSTALL ATION

Small, compact and lightweight for easy installation.

REMOTE MONITORING

Monitor your system remotely via smartphone or web portal.

Simple

All-in-one designModular installation & Quick plug connector

Technical parameters of the battery system
project name	essential parameter	remarks
product model	51.2V 100Ah
rated voltage	51.2V
rated capacity	100Ah
rated energy	5120Wh
cooling-down method	natural cooling
compound mode	16 String 1 and
Charge and discharge ports (common or split)	A total of
The communication port is RS232 / RS485 / CAN	RS485/CAN
display screen	With a display
Heating function	Default no	Can be matched first
Battery pack charging cutoff voltage	57.6V	Charging protection voltage
Battery pack discharge cut-off voltage	43.2V	Discharge to protect voltage
Single-unit charging cut-off voltage	3.65
The monomer discharge cut-off voltage	2.7
Charging operating temperature range	-0 ~ 55°C
Discharge operating temperature range	-20 ~ 60°C
Standard charging	0.2C current continuously charging to 57.6V cut-off
Standard discharge	0.5C current continuously continuously to 43.2V cutoff
Maximum allowable continuous charge current	100A
Maximum allowable continuous discharge current	100A
Discharge protects current	110A
Battery box size (length * width * height mm)	560445175mm	Dimension tolerance of ± 1.5mm
Battery Case Weight Tolerance (KG)	55	Weight tolerance of ± 3 KG
