NM-ESSM Series
- Category：Energy Storage System
- Clicknum：次
- Intro：
● Integrated design
● Pure sine wave solar inverter
● Built-in 40A MPPTsolar charger
● PV input voltage range 20~150VDC (for 1000W) 30~150VDC(for 1500W)
● Built-in anti-dust kit for harsh environment
- Detail
Features
● Integrated design
● Pure sine wave solar inverter
● Built-in 40A MPPTsolar charger
● PV input voltage range 20~150VDC (for 1000W) 30~150VDC(for 1500W)
● Built-in anti-dust kit for harsh environment
● Smart battery charge design to optimize battery life
● Meet rich customized demands
● Solar energy is provided directly to the load first
Product Data Sheet
| Model | VICTOR NM-ESSM-1.0KW PLUS-100AH | VICTOR NM-ESSM-1.5KW PLUS-100AH |
| RATED POWER | 1000W/1000VA | 1500W/1500VA |
| AC Input | ||
| Voltage | 230VAC | |
| Selectable Voltage Range | 170~280VAC(For Personal Computers) 90~280VAC(For Home Appliances) | |
| Frequency Range | 50 Hz/60Hz(Auto sensing) | |
| AC OUTPUT | ||
| AC Voltage Regulation | 230VAC±5% | |
| Surge Power | 2000VA | 3000VA |
| Efficiency(Peak)PV to INV | 98% | |
| Efficiency(Peak)Battery to INV | 94% | |
| Transfer Time | 10 ms | |
| BATTERY | ||
| Battery Voltage | 12VDC | 24VDC |
| Floating Charge Voltage | 13.5VDC | 27VDC |
| Overcharge Protection | 16VDC | 32VDC |
| SOLAR CHARGER & AC CHARGER | ||
| Solar Charger Type | MPPT | |
| Maximum PV Array Power | 600W | 1200W |
| MPPT Range @ Operating Voltage | 20~150VDC | 30~150VDC |
| Maximum PV Array Open Circuit Voltage solar | 150VDC | |
| Maximum Solar Charge Current | 40A | |
| Maximum AC Charge Current | 40A | |
| Maximum Solar+AC Charging Current | 80A | |
| BATTERY | ||
| MODEL | 12.8V100AH | 25.6V100AH |
| Normal charging voltage | 14.2V | 29.2V |
| Maximum charging current | 100A | 100A |
| Discharge termination voltage | 9.2V | 20V |
| Recommended discharge termination voltage | 10V | 22.4V |
| Maximum discharge current | 100A | 100A |
| Single cell charging overvoltage protection | 3.75V | 3.65V |
| Overvoltage protection for the whole battery | 15V | 29.2V |
| Low voltage protection for single cell discharge | 2.3V | 2.5V |
| Low voltage protection for whole group discharge | 10V | 20V |
| Charge overcurrent protection | 110A | |
| Discharge overcurrent protection | 110A | |
| BMS Features | High accuracy cell level voltage, current measuring Over-charge, over-discharge protection Short-circuit protection Self-learning intelligent SOC calculation Cell level active equalization Multiple communication type Parallel connect function | |
| Working temperature | -20℃~+65℃ | |
| Storage temperature | 0℃~+65℃ | |
| PHYSICAL | ||
| Dimension, H*W*D(mm) | 491*320*140 | |
| Cartoon Dimension, H*W*D(mm) | 570*390*230 | |
| Net Weight(kgs) | 17.3 | 32.3 |
| Gross Weight(kgs) | 19.2 | 34.5 |
| ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| STANDARD | ||
| Compliance Safety | CE UN38.3,MSDS | |
