LITHIUM BATTERY Series
- Category：Wall Mounted Lithium Battery
- Clicknum：次
- Intro：
Security Using safe and eco-friendly LiFePO4 battery, with MSDS,UN38.3,ROHS,IEC62619,UL
Capacity Expandable Support for up to 10 batteries in parallel
Latest Technology The safest, environmentally friendly Lithiumiron Phosphate technology
More Usable Energy Equipped with BMS Battery management system to intelligently manage and maintain each battery unit
- Detail
Features
Security
Using safe and eco-friendly LiFePO4 battery, with MSDS,UN38.3,ROHS,IEC62619,UL
Capacity Expandable
Support for up to 10 batteries in parallel
Latest Technology
The safest, environmentally friendly Lithiumiron Phosphate technology
More Usable Energy
Equipped with BMS Battery management system to intelligently manage and maintain each battery unit
Long lasting
6000+ Cycle Life, intelligent balance
Ultra low power consumption
Low power and no relay design, milliwatt standby loss
Grade
Quality of vehicle specification, high quality battery
High-tech
Focusing on the layout of the whole industrial chain of advanced lithium battery key materials, batteries, battery management and system integration, it has core technology intellectual property rights.
High quality
High quality, Grade A cell loss
Introduction
Product Data Sheet
| BATTERY / MODEL | 25.6V 100AH | 25.6V 200AH | 51.2V 100AH | 51.2V 200AH |
| Normal charging voltage | 29.2V | 29.2V | 58.4V | 58.4V |
| Maximum charging current | 100A | 100A/200A | 100A | 100A/200A |
| Discharge termination voltage | 21.6V | 21.6V | 43.2V | 43.2V |
| Recommended discharge termination voltage | 22.4V | 22.4V | 44.8V | 44.8V |
| Maximum discharge current | 100A | 100A | 100A | 100A |
| Single cell charging over voltage protection | 3.8V | 3.8V | 3.8V | 3.8V |
| Over voltage protection for the whole battery | 29.2V | 29.2V | 58.4V | 58.4V |
| Low voltage protection for single cell discharge | 2.7V | 2.7V | 2.7V | 2.7V |
| Low voltage protection for whole group discharge | 21.6V | 21.6V | 43.2V | 43.2V |
| Charge over current protection | 102-112A | 102-112A | 102-112A | 102-112A |
| Discharge over current protection | 102-122A | 102-122A | 102-122A | 102-122A |
| BMS Features | • High accuracy cell level voltage, current measuring • Over-charge, over-discharge protection • Short-circuit protection • Self-learning intelligent SOC calculation • Cell level active equalization • Multiple communication type • Parallel connect function | |||
| Working temperature | -20℃~+65℃ | |||
| Storage temperature | 0℃~+65℃ | |||
| Single Battery Module | Dimensions (mm) | 541*480*190 | 541*480*190 | 541*960*190 |
| Weight (Kg) | 27 | 54 | 110 | |
